Processing Materials: Combination crusher is widely used in secondary or tertiary crushing in industries such as mineral processing, building materials, coal, chemicals, and refractories. It has efficient crushing ability for hard materials such as shale, glass, ceramics, bluestone, metal ore, etc., especially in the application of machine-made sand and metal ore.
Outstanding Advantages of Combination Crusher
1.Simple structure and strong crushing force. With advanced crushing technology and digital processing equipment, the internal structure of the compound crusher is precise and the crushing capacity is enhanced.
2.Less noise and less dust. Strictly meet the national environmental standards with low noise and equipped with dust removal equipment to reduce dust generation and reduce pollution.
3.Convenient operation and maintenance. The equipment is easy to operate during use, and the maintenance work is convenient and fast, which reduces the downtime for maintenance.
4. High production efficiency. There is no dead zone and material blocking in deep cavity crushing. single machine energy saving 15%-30%, and system energy saving more than doubled.
5. Advanced manufacturing, strong pressure, and wear resistance. The parts are made of high-quality materials, the movable jaw is made of steel casting, and the eccentric shaft is processed by forging billet, which enhances the compression resistance and wears resistance.
6. Wide application. The adjustment range of the discharge opening is large, the structure is reasonable, and the occupied area is small, which can meet the various processing needs of users.
Safety Operation Regulations of Combination Crusher
1.Before starting the machine, check whether the bin door of the compound crusher body is tightly closed, and open the bin door to make the machine stop stably to prevent danger.
2.The compound crusher must be started with no load and can only be produced after normal operation.
3.The particle feeding size should be in accordance with the specified requirements, if the size is too large, the equipment will be damaged.
4.If any abnormal phenomenon is found in the crushing process, the inspection shall be stopped and the production shall be carried out after troubleshooting.
5. Add lubricating oil to the rotating bearing parts of the compound cone crusher regularly.
Technical Parameters of Combination Crusher
Model | PFL-800 | PFL-1000 | PFL-1250 | PFL-1500 | PFL-1750 |
Motor diameter(mm) | 650 | 800 | 1000 | 1250 | 1560 |
Barrel height(mm) | 800 | 850 | 850 | 1000 | 1410 |
Shaft speed(r/min) | 1350 | 970 | 740 | 650 | 600 |
Input size(mm) | 50 | 70 | 100 | 100 | 100 |
Output size(mm) | 0-5 | ||||
Capacity(t/h) | 5-15 | 10-30 | 20-60 | 30-80 | 40-100 |
Motor Power | 30 | 55 | 75 | 110 | 132 |
Rotor speed(r/min) | 1440 | 1440 | 750 | 750 | 750 |
Weight | 2.3 | 4.5 | 9.73 | 18.1 | 26.61 |
Diemension(m) | 2.2*0.86*1.98 | 2.7*1.16*2 | 2.8*1.4*2.73 | 3.1*1.9*2.3 | 3.35*2.1*2.8 |
