Applied Field: Gold grinding mill machine is mainly used for the separation and grinding of gold, silver, lead, zinc, iron, copper, antimony and other minerals. Gold grinding mill machine can process all the materials that can be grinded by the ball mill.
Characteristic of Gold Grinding Mill Machine
The gold grinding mill machine mainly through the mixing, rolling, and grinding of raw materials repeatedly to achieve water balance, uniform ratio, low air content, and improve the molding rate and molding quality. The product of gold grinding mill machine has the characteristics of high density, good strength, and non-porous proportion, which is used for the recovery of tailings in iron ore process flow and makes full use of effective resources without the loss of ore powder.
Installation and Commissioning of Gold Grinding Mill Machine
1.The gold grinding mill machine should be installed on the horizontal concrete foundation, and a thin leather or square wood should be laid between the machine frame and the ground to reduce the vibration. Special attention should be paid not to fix the gold grinding mill machine frame on the ground with anchor bolts!
2.When installing, pay attention to the level between the main body and the ground of the gold grinding mill machine, take the center spindle of the shelf as the center to correct the basin and the ground.
3.After installation, check whether the bolts at all parts of the gold grinding mill machine are loose. If any, tighten them.
4.Configure the power cord and control switch according to the power of the gold grinding mill machine.
5. After inspection, a small amount of ore is added for a trial run of the gold grinding mill machine. After half an hour of the test run, the bolts on the gold grinding mill machine can be reinforced. After repeating this two or three times, normal production for gold grinding mill machine can be achieved!
Model | Gauge (mm) | Feed Size | Engine power | Rotation speed | Weight |
1600A | 1600×400×200×500±20 | ≤25 | 6-30 | 20-22 | 14.5 |
1500A | 1500×350×200×460±20 | ≤25 | 6-22 | 20-22 | 13.3 |
1500B | 1500×350×150×460±20 | ≤25 | 6-22 | 20-22 | 12.3 |
1500C | 1500×300×150×420±20 | ≤25 | 6-22 | 20-22 | 11.3 |
1400A | 1400×250×150×350±20 | ≤25 | 6-18.5 | 16-18 | 8.5 |
1400B | 1400×250×150×350±20 | ≤25 | 6-18.5 | 21-23 | 8.5 |
1350A | 1350×250×150×350±20 | ≤25 | 6-18.5 | 16-18 | 8 |
1350B | 1350×250×150×350±20 | ≤25 | 6-18.5 | 21-23 | 8 |
1300A | 1300×250×150×350±20 | ≤25 | 6-15 | 16-18 | 7.5 |
1300B | 1300×200×150×350±20 | ≤25 | 4-15 | 21-23 | 7.5 |
1200A | 1200×220×80×270±20 | ≤25 | 6-7.5 | 17-19 | 5.5 |
1200B | 1200×200×80×250±20 | ≤25 | 6-7.5 | 23-25 | 5.5 |
1100A | 1100×200×80×250±20 | ≤25 | 6-7.5 | 17-19 | 5 |
1100B | 1100×180×80×250±20 | ≤25 | 4-7.5 | 23-25 | 5 |
1000 | 1000×200×80×250±20 | ≤25 | 4-7.5 | 13-15 | 4.5 |
