Processing Materials: PF impact crusher has the advantages of simple structure, high crushing ratio, low energy consumption, high output, and cubic shape finished product. PF impact crusher plant can be used for crushing materials with compressive strength not higher than 100Mpa, such as limestone, clinker, slag,coal, etc. Applied Field: PF impact crusher is widely used in mining, cement, construction, refractory materials, coal, and glass industry.
Working Principle of PF Impact Crusher
Thepfimpact crusher is high-efficiency crushing equipment that crushes materials along crystalline boundaries and fragile textures.
Advantages of PF Impact Crusher
1.The uniform plate structure of pf impact crusher makes the discharge more small particle size and cubic shape without internal crack.
2.The low and large feeding portofpf impact crusheris convenient for the production line layout and feed size increasing.
3.PF impact crusher has a full hydraulic opening, which easies to repair and replace wearing parts.
4.The new wear-resistant material makes the hammer, impact plate and liner of pf impact crusher have a longer service life.
5.The plate hammer of pf impact crusher has the characteristics of fast loading and unloading and multiple transpositions, which can shorten the replacement time of plate hammer.
Model | Rotor Size | Feed Openning Size | Max. Feeding Size | Output Size | Capacity | Motor Power |
PF-0607 | 644*740 | 320*770 | 100 | 5-60 | 10-20 | 30 |
PF-0807 | 850*700 | 400*730 | 300 | 5-60 | 15-30 | 30-45 |
PF-1008 | 1000*800 | 400*830 | 300 | 5-60 | 30-50 | 37-55 |
PF-1010 | 1000*1050 | 400*1080 | 350 | 5-60 | 50-80 | 55-75 |
PF-1210 | 1250*1050 | 400*1080 | 350 | 5-60 | 70-120 | 110-132 |
PF-1212 | 1250*1250 | 400*1300 | 350 | 5-60 | 100-120 | 132-160 |
PF-1214 | 1250*1400 | 400*1430 | 400 | 5-60 | 130-180 | 160-200 |
PF-1315 | 1320*1500 | 680*1520 | 400 | 5-60 | 160-250 | 180-260 |
PF-1320 | 1320*2000 | 680*2030 | 400 | 5-60 | 300-350 | 300-375 |
