Processing Materials: Diesel engine jaw crusher is applied in various industries, such as mining, road and railway construction, building construction, chemical industry and water conservation etc. It's mainly for crushing kinds of minerals and rocks with compression strength less than 320MPa, such as granite, quartz, basalt, limestone, river stone, sandstone, shale, iron ore, copper ore, gold ore etc.
Main Features of Diesel Engine Jaw Crusher
1.Easy to transport and install. Diesel engine jaw crusher is easy to transport and install, which can be pulled behind a pickup truck and is the perfect crusher choice for the contractors who need to travel a lot.
2.Diesel engine installed. The diesel engine jaw crusher comes with a diesel engine installed. Combining the engine with the jaw crusher saves time and money, it shortens users' transportation time, fuel costs, and the total cost of operation, due to the cost of the engine is included with the jaw crusher.
3.Adjustable size of final products. Diesel engine jaw crusher can crush material down to sizes ranging from 5 to 10 mm. The wide range of output sizes can create crushed rock for a variety of applications, from aggregate production to mineral ore processing.
Precautions about Diesel Engine Jaw Crusher
1.The diesel engine jaw crusher can be put into production after normal operation.
2.The materials to be crushed should be evenly added into the diesel engine jaw crusher cavity, and lateral feeding or full charging should be avoided to unilateral overload.
3.During normal operation of diesel engine jaw crusher, the temperature rise of the bearing should not exceed 30℃, and the high temperature should not exceed 70℃. When the temperature is higher than the above, stop the machine immediately, find out the cause, and eliminate it.
4.Before stopping the jaw crusher, the feeding should be stopped first, and the power supply can be turned off after the materials in the crushing cavity are completely discharged.
5.During crushing, if the machine stops due to the blockage of the materials in the crushing chamber, the power supply should be turned off immediately to stop the operation and the materials in the crushing chamber can be cleaned up before starting again.
6. After one end of the jaw is worn, it can be used in an adjustable direction.
7. After the crusher is used for a period of time, the bushing should be tightened to avoid loosening and damaging the machine.
Technical Parameters of Diesel Engine Jaw Crusher
Model | Max. feeding size | Discharge size | Capacity | Motor power | Weight |
PE150*250 | 125 | 10-40 | 1-3 | 5.5 | 0.7 |
PE250*400 | 210 | 20-60 | 5-20 | 15 | 2.8 |
