Processing Materials: Diesel powered jaw crusher is widely used for crushing various materials like granite, basalt, limestone, river stone, sandstone, copper ore, building construction, construction wastes etc.with compression strength less than 350 Mpa. It is widely used in road & bridge construction, metallurgy and other fields to crusher and screen.
Structure of Diesel Powered Jaw Crusher
The eccentric shaft of diesel-powered jaw crusher adopts 40Cr steel precise forged, advanced movable jaw plate assemble which made from high-quality casting parts, tooth-shaped plate, and deep V-chamber. High manganese steel material and precise casting heavy flywheel make the crusher more reliable. Diesel-powered jaw crusherframe adopts thick heavy steel plate welding process with machine blasting, anti-rust painting, surface painting at least three times paintings.
Main Features of Diesel Powered Jaw Crusher
1.The crushing chamber of the diesel-powered jaw crusher is deep without a dead zone, which improves the feeding capacity and output.
2.The crushing ratio is large and the product size is uniform.
3.The gasket type discharge port adjusting device of the diesel-powered jaw crusher is reliable and convenient, with a large adjustment range, which increases the flexibility of the equipment.
4.The lubrication system is safe and reliable, the replacement of parts is convenient, and the equipment maintenance is simple.
5.It has the advantages of simple structure, reliable operation, and low operating cost.
6.Energy saving of equipment. The Energy-saving of a single machine is 15% - 30%, and the energy saving of a system is more than twice.
7. The adjustment range of the discharge port is large, which can meet the requirements of different usersfor diesel powered jaw crusher.
Technical Parameters of Diesel Powered Jaw Crusher
Model | Max. feeding size | Discharge size | Capacity | Motor power | Weight |
PE150*250 | 125 | 10-40 | 1-3 | 5.5 | 0.7 |
PE250*400 | 210 | 20-60 | 5-20 | 15 | 2.8 |
