Applied Field: Mini jaw crusher is the earlier crushing equipment. Because of its simple structure, reliable work, easy maintenance and repair, and relatively low production and construction costs, it is still widely used in metallurgy, chemical industry, building materials, electric power, and other industrial industries for coarse, medium, and fine crushing of various ores and rocks with compressive strength of 147～245MPa.
Characteristics of Mini Jaw Crusher
1. Mini jaw crusher has a high yield and good grain shape. Its crushing chamber is deep without a dead zone, and the material handling capacity is relatively large.
2. The coordination of the mini jaw crusher machine between the components is reasonable and the operation is stable and safe.
3.The mini jaw crusher has relatively low working noise and less dust, which can reduce environmental pollution.
4. The adjustment range of discharge port of the mini stone jaw crusher is relatively large, and the adjustment is flexible and fast, which can meet different production requirements.
Factors Affecting the Price of MiniJaw Crushers
1. Quality
The quality of the equipment determines the production process and results. Good quality means that the raw materials of the mini jaw crusher are better, and the price will definitely be higher.
2.Technology
Different manufacturers of mini jaw crusher plant have different advanced technology levels, different production processes, different crushing capabilities, so the price difference is also relatively large.
3. Region
The consumption level, the number of manufacturers, the cost of raw materials, etc. are different in each region, so the price of mini jaw crusher is different in each region.
Technical Parameters of Mini Jaw Crusher
Model | Max. feeding size (mm) | Discharge size (mm) | Capacity (t/h) | Motor power (kw) | Weight (t) | Diemension (mm) |
PE150*250 | 125 | 10-40 | 1-3 | 5.5 | 0.7 | 1000*870*990 |
PE250*400 | 210 | 20-60 | 5-20 | 15 | 2.8 | 1300*1090*1270 |
PE400*600 | 340 | 40-100 | 16-60 | 30 | 7 | 1730*1730*1630 |
PE400*900 | 340 | 40-100 | 40-110 | 55 | 7.5 | 1905*2030*1658 |
PE500*750 | 425 | 50-100 | 40-110 | 55 | 12 | 1980*2080*1870 |
PE600*900 | 500 | 65-160 | 50-180 | 75 | 17 | 2190*2206*2300 |
PE750*1060 | 630 | 80-140 | 110-320 | 90 | 31 | 2660*2430*2800 |
PE900*1200 | 750 | 95-165 | 220-450 | 160 | 52 | 3380*2870*3330 |
PE1000*1200 | 850 | 195-265 | 315-500 | 160 | 55 | 3480*2876*3330 |
PEX150*750 | 120 | 18-48 | 8-25 | 15 | 3.8 | 1200*1530*1060 |
PEX250*750 | 210 | 15-60 | 13-35 | 30 | 6.5 | 1380*1750*1540 |
PEX250*1000 | 210 | 15-60 | 16-52 | 37 | 7 | 1560*1950*1390 |
PEX250*1200 | 210 | 15-60 | 20-61 | 45 | 9.7 | 2140*2096*1500 |
