Processing Materials: Jaw crusher pe 400x600 is used to crush all kinds of ores or rocks with compressive strength below 250Mpa, such as river stone, limestone, granite, quartzite, limestone, bluestone etc. Applied Field: Jaw crusher pe 400x600 is widely used in large and medium-sized ores, quarries, building materials, mining, metallurgy, construction, etc fields.
Parameter analysis of Jaw Crusher Pe 400x600
Jaw Crusher Pe 400x600: feeding size is not more than 340mm, discharge port adjustment range is 40-100 mm, processing capacity is 16-60 T / h. The following is a detailed introduction regarding the feeding size, discharge port adjustment range, processing capacity, and overall dimension of jaw crusher pe400x600.
1.The feeding size mainly refers to the limit value of material size that can be processed by jaw crusherpe400x600.
2.The adjustment range of the discharge openingof jaw crusherpe400x600, which refers to the size of the crushed material, generally has a certain range. Customers can adjust it according to their needs.
3.Processing capacity refers to the number of materials that can be processed by a jaw crusherpe400x600 in one hour.
4.The overall dimension refers to the length, width, and height of the jaw crusherpe400x600.
Price of Jaw CrusherPE400x600
The cost of manpower and material resources invested by different manufacturers in the production of jaw crusherpe400x600 is different, so different manufacturers have certain different prices about the jaw crusherpe400x600.
The crushing efficiency of Nile jaw crusherpe400x600 is high and the service life of its wearing parts is doubled compared with other manufacturers, which help customers save a lot of money to replace accessories. Free online consultation here to get our jaw crusherpe400x600 price.
Technical Parameters
Model | Max. feeding size (mm) | Discharge size (mm) | Capacity (t/h) | Motor power (kw) | Weight (t) | Diemension (mm) |
PE150*250 | 125 | 10-40 | 1-3 | 5.5 | 0.7 | 1000*870*990 |
PE250*400 | 210 | 20-60 | 5-20 | 15 | 2.8 | 1300*1090*1270 |
PE400*600 | 340 | 40-100 | 16-60 | 30 | 7 | 1730*1730*1630 |
PE400*900 | 340 | 40-100 | 40-110 | 55 | 7.5 | 1905*2030*1658 |
PE500*750 | 425 | 50-100 | 40-110 | 55 | 12 | 1980*2080*1870 |
PE600*900 | 500 | 65-160 | 50-180 | 75 | 17 | 2190*2206*2300 |
PE750*1060 | 630 | 80-140 | 110-320 | 90 | 31 | 2660*2430*2800 |
PE900*1200 | 750 | 95-165 | 220-450 | 160 | 52 | 3380*2870*3330 |
PE1000*1200 | 850 | 195-265 | 315-500 | 160 | 55 | 3480*2876*3330 |
PEX150*750 | 120 | 18-48 | 8-25 | 15 | 3.8 | 1200*1530*1060 |
PEX250*750 | 210 | 15-60 | 13-35 | 30 | 6.5 | 1380*1750*1540 |
PEX250*1000 | 210 | 15-60 | 16-52 | 37 | 7 | 1560*1950*1390 |
PEX250*1200 | 210 | 15-60 | 20-61 | 45 | 9.7 | 2140*2096*1500 |
