The Jaw Crusher 400*600 is mainly used for crushing medium-sized particles of various ores and bulk materials, and is widely used in mining, smelting, building materials, highways, railways, water conservancy and chemical industries.
Product Description
The Jaw Crusher 400*600 is mainly used for crushing medium-sized particles of various ores and bulk materials, and is widely used in mining, smelting, building materials, highways, railways, water conservancy and chemical industries. It is mainly composed of frame, jaw plate and side guard plate, transmission parts, adjusting device, flywheel, lubrication device, etc. In addition, the crushing cavity of the Jaw Crusher 400*600 is deep and has no dead zone, which improves the feeding capacity and outputo the equipment. It uses a gasket-type discharge opening adjustment device, which is reliable and convenient, has a large adjustment range, and increases the flexibility of the equipment. It also has the advantages of simple structure, low manufacturing cost, convenient maintenance, reliable work, small machine height, and easy configuration.The Jaw Crusher 400*600 receives a good reputation among our clients worldwide due to excellent performance.
Benefits ofJaw Crushers
Open back for easilymaintenance
Deep crushing cavity and energy efficiency
Strong stability, long service life
Wide range of the discharging adjustment and multi-purpose
Simple operation, convenient maintenance
Low noise and dust
High crushing efficiency
High wear-resistant plates and protection plates
Widely used for crushing process of various metal ores and non-metal ores.
Technical Parameters
Model | Max. feeding size (mm) | Discharge size (mm) | Capacity (t/h) | Motor power (kw) | Weight (t) | Diemension (mm) |
PE150*250 | 125 | 10-40 | 1-3 | 5.5 | 0.7 | 1000*870*990 |
PE250*400 | 210 | 20-60 | 5-20 | 15 | 2.8 | 1300*1090*1270 |
PE400*600 | 340 | 40-100 | 16-60 | 30 | 7 | 1730*1730*1630 |
PE400*900 | 340 | 40-100 | 40-110 | 55 | 7.5 | 1905*2030*1658 |
PE500*750 | 425 | 50-100 | 40-110 | 55 | 12 | 1980*2080*1870 |
PE600*900 | 500 | 65-160 | 50-180 | 75 | 17 | 2190*2206*2300 |
PE750*1060 | 630 | 80-140 | 110-320 | 90 | 31 | 2660*2430*2800 |
PE900*1200 | 750 | 95-165 | 220-450 | 160 | 52 | 3380*2870*3330 |
PE1000*1200 | 850 | 195-265 | 315-500 | 160 | 55 | 3480*2876*3330 |
PEX150*750 | 120 | 18-48 | 8-25 | 15 | 3.8 | 1200*1530*1060 |
PEX250*750 | 210 | 15-60 | 13-35 | 30 | 6.5 | 1380*1750*1540 |
PEX250*1000 | 210 | 15-60 | 16-52 | 37 | 7 | 1560*1950*1390 |
PEX250*1200 | 210 | 15-60 | 20-61 | 45 | 9.7 | 2140*2096*1500 |
