Circular Vibrating Sieve

Working Principle of Circular Vibrating Sieve

Circular vibrating sieve uses the common motor to drive the vibrator outside to make the screen body periodically along the direction of exciting force, and the materials move in a circle on the screen surface to achieve the purpose of screening.

Featuresof Circular Vibrating Sieve

1.Circular vibrating sieve has two lubrication modes, grease lubrication, and thin oil lubrication, and the lubricating oil is changed every 1000 hours.

2.The exciting force of circular vibrating sieve is larger with a screening efficiency of 85%, the screening purity is higher and more thorough, and the exciting force can be adjusted randomly. It has low noise and convenient maintenance.

3.The circular vibrating sieve has various forms, with many layers, higher screening clarity, more thorough screening, convenient and fast installation.

4.The screen mesh of circular vibrating sieve is various, without blocking the hole, and there are many discharging specifications. The circular vibrating sieve machine has higher screening efficiency, larger processing capacity, longer service life, and overall service life.

5.Adopt the cross shaft universal joint transmission shaft or rubber coupling and other flexible connections, so it runs smoothly.

6. Damping spring: there are two kinds of spring in this machine, one is a metal spring and the other is a natural rubber spring.
