Processing Materials: Jaw crushers for rock are used as coarse crushing, medium crushing equipment for various ores or rocks with compressive strength below 300Mpa. Applied Field: Jaw crushers for rock are suitable for metallurgy, mining, construction, transportation, cement, and other industries.
Ways to reduce the wear of jaw crusher for rock
1.The liner of jaw crusher is easy to wear. It's the most direct way to reduce wear by using a liner with good wear resistance.
2.Good design can make the utilization of jaw crusher for rock better and avoid wear and tear of spare parts. A good design of parts can transfer the waste energy caused by friction to the crushing of raw materials and reduce the wear of related parts. At the same time, it can make energy utilization better and improve the performance of jaw crusher for rock.
3.The production of jaw crusher for rock is large, so it is necessary to regularly overhaul and maintain the equipment. At the same time, good maintenance can reduce the rate of wear and failure, and enable the equipment to perform better.
4.In view of the wear surface of the jaw crusher for rock, do a good job of lubrication to reduce the friction between them. At the same time, it is necessary to lubricate the bearings and other parts in the jaw crusher to make it play an important role in reducing wear.
Factors affecting the price of jaw crusher for rock
1.How it works on materials
2.Movement rulesof moving jaw
3.The nature of the material
4.Movement of toothed plate
Technical Parameters
Model | Max. feeding size (mm) | Discharge size (mm) | Capacity (t/h) | Motor power (kw) | Weight (t) | Diemension (mm) |
PE150*250 | 125 | 10-40 | 1-3 | 5.5 | 0.7 | 1000*870*990 |
PE250*400 | 210 | 20-60 | 5-20 | 15 | 2.8 | 1300*1090*1270 |
PE400*600 | 340 | 40-100 | 16-60 | 30 | 7 | 1730*1730*1630 |
PE400*900 | 340 | 40-100 | 40-110 | 55 | 7.5 | 1905*2030*1658 |
PE500*750 | 425 | 50-100 | 40-110 | 55 | 12 | 1980*2080*1870 |
PE600*900 | 500 | 65-160 | 50-180 | 75 | 17 | 2190*2206*2300 |
PE750*1060 | 630 | 80-140 | 110-320 | 90 | 31 | 2660*2430*2800 |
PE900*1200 | 750 | 95-165 | 220-450 | 160 | 52 | 3380*2870*3330 |
PE1000*1200 | 850 | 195-265 | 315-500 | 160 | 55 | 3480*2876*3330 |
PEX150*750 | 120 | 18-48 | 8-25 | 15 | 3.8 | 1200*1530*1060 |
PEX250*750 | 210 | 15-60 | 13-35 | 30 | 6.5 | 1380*1750*1540 |
PEX250*1000 | 210 | 15-60 | 16-52 | 37 | 7 | 1560*1950*1390 |
PEX250*1200 | 210 | 15-60 | 20-61 | 45 | 9.7 | 2140*2096*1500 |
