Processing Materials:Marble, bluestone, river pebble, granite, basalt, iron ore, limestone, quartzite, sandstone, construction waste, coal gangue, gold ore and so on. Applications Field:sand and gravel , building materials, roads, chemicals and other fields.
Advantages:
1.Structure simplification: With the continuous progress of mining technology, jaw crushing machine is also constantly improved and optimized. In recent years, the structure of jaw crusher machine has also been simplified while the performance of the jaw crusher plant has been improved. It shortens the maintenance time and improves the working efficiency of the jaw crushing machine, which conforms to the simple and efficient development trend required by society.
2.Low cost: Stone jaw crushers are more economical choices when comparing with other machines. They are designed to provide good performance, while important parts such as jaw plates, bearings and frames can be protected for longer service life.
3.Large crushing ratio: The crushing ratio is an important evaluation index for the jaw crushing machine. Jaw crushing plant can complete the crushing of large limestone with feeding size is 1000 * 1200mm.
Our Services
Nile Machinery owns an experienced and skilled sales and service team. Our professional engineers will visit the customer sites and provide guidance for the installation, commissioning, and initial run as well as planning administration of the equipment after purchasing the jaw crushing machine.
Technical Parameters
Model | Max. feeding size (mm) | Discharge size (mm) | Capacity (t/h) | Motor power (kw) | Weight (t) | Diemension (mm) |
PE150*250 | 125 | 10-40 | 1-3 | 5.5 | 0.7 | 1000*870*990 |
PE250*400 | 210 | 20-60 | 5-20 | 15 | 2.8 | 1300*1090*1270 |
PE400*600 | 340 | 40-100 | 16-60 | 30 | 7 | 1730*1730*1630 |
PE400*900 | 340 | 40-100 | 40-110 | 55 | 7.5 | 1905*2030*1658 |
PE500*750 | 425 | 50-100 | 40-110 | 55 | 12 | 1980*2080*1870 |
PE600*900 | 500 | 65-160 | 50-180 | 75 | 17 | 2190*2206*2300 |
PE750*1060 | 630 | 80-140 | 110-320 | 90 | 31 | 2660*2430*2800 |
PE900*1200 | 750 | 95-165 | 220-450 | 160 | 52 | 3380*2870*3330 |
PE1000*1200 | 850 | 195-265 | 315-500 | 160 | 55 | 3480*2876*3330 |
PEX150*750 | 120 | 18-48 | 8-25 | 15 | 3.8 | 1200*1530*1060 |
PEX250*750 | 210 | 15-60 | 13-35 | 30 | 6.5 | 1380*1750*1540 |
PEX250*1000 | 210 | 15-60 | 16-52 | 37 | 7 | 1560*1950*1390 |
PEX250*1200 | 210 | 15-60 | 20-61 | 45 | 9.7 | 2140*2096*1500 |
