Symons cone crusher has a variety of crushing cavity types, its structure is relatively complex, the manufacturing precision of mechanical parts is relatively high, and it needs good maintenance to run normally for a long time. The following is a detailed introduction to the repair and maintenance methods of Symons cone stone crusher.
Installation and commissioning of Symons cone crusher machine
1. The equipment should be installed on a level concrete foundation and fixed with anchor bolts.
2. Pay attention to the verticality of the main body and the horizontal when installing.
3. After installation, check whether the bolts of each part are loose and whether the main engine compartment door is fastened. If so, please fasten it.
4. Configure the power cord and control switch according to the power of the equipment.
5. After the inspection is completed, a no-load test run is carried out, and the test run is normal and production can be started.
Maintenance and maintenance of Symons cone crushing machine
1. Maintenance of machine bearings
The shaft of the Symons cone crusher equipment bears the full load, so good lubrication is very important to the service life of the bearing, but also related to the service life and work efficiency of the machine. This machine mainly adds lubricating oil to rotating bearings, roller bearings, all gears, movable bearings, sliding planes, etc. Note that the added lubricating oil must be clean without any impurities, and the seal must be good.
2. Inspection of each component
The newly installed wheel tires are prone to looseness and must be checked frequently. In addition, regularly check the degree of wear of easily worn parts, and replace severely worn parts in time to avoid unnecessary failures.
3. Stop and check when a fault occurs
When the bearing temperature of the Simmons cone crusher rises and the rotating gear has an impact sound during operation, the operator should stop immediately to check the cause and solve the problem, so as not to affect the work efficiency. If we don't know the specific reasons, don't operate blindly, we should find professional technicians for repairs.
4. Remove debris in time
Operators should remove dust and other debris on the plane of the bottom frame of the movable device of the Symons cone crusher in time, and the movable bearing cannot move on the bottom frame when the machine encounters unbreakable materials, which may cause serious accidents.
5. Clean the oil supply filter in time
The oil in the hydraulic station needs to be filtered and used for about three months. Due to poor working conditions, large dust, lubricating oil is easy to be contaminated and the oil quality deteriorates, it is necessary to check and clean the oil supply filter, the oil return filter, the filter screen, and the change of the oil quality every month. Keep the working pressure between 0.08-0.15MPa.
The above is a detailed introduction to the installation and maintenance of the Symons stone cone crusher machine so that our machine has a longer service life. If you want to know more about the mining industry, please consult our customer service online.
