Cone Crusher Hp300

Maintenanceof Cone Crusher Hp300

1.Replacement of crushing wall of cone crusher Hp300

The conical fracture wall is fixed on the main body of the cone with a conical head, and the zinc alloy is cast between them. After 6-8 hours of the replacement of a new conical fracture wall, the tightening condition should be checked immediately.

2.Gear meshing

Friction causes disc wear, which affects the change of gear clearance. In order to ensure the normal meshing of the gear, a gasket must be added to the bottom cover. And the thickness of the gasket should be equal to the wear amount of the circular plate.

3. Bowl bearing and sealing device

When installing the bowl bearing, take care not to damage the oil slinger (supported by hardwood or analogues between the ropes). During the assembling process, the supporting spherical surface shall be scraped to ensure that the broken cone and bowl shaped mutual spherical surface are in contact with the inner circle in the outer ring and the annular clearance is 0.35-0.5 mm. The bowl bearing bushing of cone crusher Hp300 is fixed to the bowl bearing frame by surrounding Bain alloy locking bolts to prevent the bowl bearing bush from rotating along the circumference. The bowl bearing frame and frame body of cone crusher Hp300 are fixed by a key (PIN). If there is a gap between the bowl bearing frame and the frame body, it needs to be treated immediately.

4.The cylindrical bushing and frame of the cone crusher Hp300 are the third transition fit. When replacing a new bushing, it should be prepared according to the actual size of the frame of the stone cone crusher Hp300. If the clearance is too large, the bushing will be broken.

The exposed parts of the cone crusher Hp300should be covered with protective cover.

Advantagesof Cone Crusher Hp300

1.Cone Crusher Hp300 adopts hydraulic operation, which is more stable, reliable, and easy to operate, reduces downtime, and realizes fully automatic operation.

2.The high degree of automation of Cone Crusher Hp300control makes the operation easier.

3.The Cone Crusher Hp300 has a unique structurethat has thestrong bearing capacity, small size, high efficiency and low noise.
