Processing Materials: Cone crusher plant is able to break all kinds of hard stone and rock materials with compressive strength not exceeding 350MPa, such as: river pebble, granite, basalt, iron ore, shale, limestone, coal gangue, quartz stone,marble etc. Applicable Fields: Cone crusher plant is applied to mine, metallurgy, construction, chemical, electric power, transportation, and other industries.
Precautions for cone crusher plant operation
1.The ore must be given in the middle of the distribution plate. It is not allowed to feed the ore directly into the crushing cavity, which will cause uneven wear of the lining and overload of the cone crusher plant. The correct ore feeding conditions are as follows: the ore is evenly dispersed in the crushing cavity through the distribution plate, and the ore to be fed cannot be higher than the height of the rolling wall.
2.The ore size should be less than or equal to 85% of the feeding mouth size of the cone crusher plant, otherwise, it will lead to the reduction of the crusher output and the damage of some parts of the cone crusher plant.
3.The crusher is not allowed to start with load, which will cause accidents.
4.When parking, it must stop the mining machine first and let the cone crusher plant stop after the ore which in the cavity is crushed and discharged.
5.When the cone crusher pant is working, the pressure of the locking system and the working condition of the hydraulic station should be checked frequently, and the problems should be solved in time.
Factors affecting the price of cone crusher plant
The price of the cone crusher plant is comprehensively based on the demand and conditions of the market, labor costs, publicity costs, and manufacturing technology used in our production process. At present, the competition in the mining machinery industry is very fierce, so even well-known manufacturers like Nile Machinery have adopted the method of small profits and high sales to sell equipment, so Nile Machinery has a high market share of cone crusher plants.
Technical Parameters
Model NO. | Type of Cavity | Output Size (mm) | Max. Feeding Size (mm) | Capacity (t/h) | Motor Power (kw) | Moving cone Diemeter (mm) |
HPY200 | C | 13 | 150 | 120-240 | 160 | 950 |
F | 6 | 76 | 55-180 | 160 | 950 | |
HPY300 | C | 13 | 225 | 150-430 | 220 | 1160 |
F | 6 | 86 | 90-260 | 220 | 1160 | |
HPY400 | C | 13 | 290 | 190-610 | 315 | 1400 |
F | 6 | 100 | 108-320 | 315 | 1400 | |
HPY500 | C | 13 | 320 | 230-700 | 400 | 1500 |
F | 6 | 110 | 145-430 | 400 | 1500 | |
HPY600 | C | 13 | 350 | 325-1150 | 630 | 1800 |
F | 8 | 120 | 245-730 | 630 | 1800 |
