Applied Fields: Cone crushing equipment can be used for secondary and tertiary crushing, and is commonly used in medium hard rock crushing in mining, metallurgy, construction, aggregate, and other industries. The crushing frequency and eccentricity of cone crusher equipment are designed reasonably with a better fine crushing effect, and the production capacity is higher, and the product shape of three-dimensional meets the needs of customers.
Technical Parameters
Model NO. | Cavity Type | Max. Feeding size (mm) | Output size (mm) | Capacity (t/h) | Motor Power (kw) | Weight (t) |
PSGB0607 | Standard fine | 60 | 6-30 | 16-50 | 22 | 4.5 |
PSGB0609 | Standard medium | 80 | 10-38 | 18-65 | 22 | 4.5 |
PSGB0611 | Standard coarse | 90 | 13-38 | 22-70 | 22 | 4.5 |
PSGD0603 | Short head fine | 35 | 3-13 | 9-35 | 22 | 4.5 |
PSGD0605 | Short head coarse | 50 | 5-16 | 22-70 | 22 | 4.5 |
PSGB0910 | Standard fine | 85 | 9-22 | 45-91 | 75 | 9.98 |
PSGB0917 | Standard coarse | 150 | 13-38 | 59-163 | 75 | 9.98 |
PSGB0918 | Standard extra coarse | 150 | 25-38 | 118-163 | 75 | 9.98 |
PSGD0914 | Short head fine | 35 | 3-13 | 27-90 | 75 | 10.53 |
PSGD0906 | Short head medium | 65 | 3-16 | 27-100 | 75 | 10.53 |
PSGD0907 | Short head coarse | 85 | 6-19 | 59-129 | 75 | 10.53 |
PSGB1313 | Standard fine | 115 | 13-31 | 109-181 | 160 | 22.46 |
PSGB1321 | Standard medium | 178 | 16-38 | 132-253 | 160 | 22.46 |
Working Principle of Cone Crushing Equipment
When working, the rotation of the motor drives the pulley or coupling, the transmission shaft and the cone to make the eccentric shaft perform periodic swing motion under the axis line. After the material enters the crushing cavity from the material port, it is crushed due to the mutual impact of the eccentric shaft and the wall of the rolling mortar, squeezing, grinding, and kneading. The hydraulic safety system can hydraulically remove the faulty material from the support sleeve and the top of the fixed cone when the machine has an iron failure or a stuffy car. Cone-crushing equipment plays a good insurance role and greatly reduces the maintenance rate.
Advantages of Cone Crushing Equipment
1.Cone crushing equipment is the use of a control computer to calculate the size of the ore discharge port, which can be adjusted in the load operation without any interruption of ore feeding, greatly reducing the labor intensity and time of the adjustment of the ore discharge port.
2.All parts can be disassembled and repaired from the top or side so that the maintenance and overhaul of the equipment are very convenient.
3.The unique lamination crushing function of the equipment makes the crushed material more uniform and the product shape neater.
4. The equipment can quickly clean the crushing cavity, reduce the workload required to clear the materials blocked in the crushing cavity, thus shortening the downtime.
Technical Parameters of Cone Crushing Equipment
Model NO. | Cavity Type | Max. Feeding size (mm) | Output size (mm) | Capacity (t/h) | Motor Power (kw) | Weight (t) |
PSGB0607 | Standard fine | 60 | 6-30 | 16-50 | 22 | 4.5 |
PSGB0609 | Standard medium | 80 | 10-38 | 18-65 | 22 | 4.5 |
PSGB0611 | Standard coarse | 90 | 13-38 | 22-70 | 22 | 4.5 |
PSGD0603 | Short head fine | 35 | 3-13 | 9-35 | 22 | 4.5 |
PSGD0605 | Short head coarse | 50 | 5-16 | 22-70 | 22 | 4.5 |
PSGB0910 | Standard fine | 85 | 9-22 | 45-91 | 75 | 9.98 |
PSGB0917 | Standard coarse | 150 | 13-38 | 59-163 | 75 | 9.98 |
PSGB0918 | Standard extra coarse | 150 | 25-38 | 118-163 | 75 | 9.98 |
PSGD0914 | Short head fine | 35 | 3-13 | 27-90 | 75 | 10.53 |
PSGD0906 | Short head medium | 65 | 3-16 | 27-100 | 75 | 10.53 |
PSGD0907 | Short head coarse | 85 | 6-19 | 59-129 | 75 | 10.53 |
PSGB1313 | Standard fine | 115 | 13-31 | 109-181 | 160 | 22.46 |
PSGB1321 | Standard medium | 178 | 16-38 | 132-253 | 160 | 22.46 |
