Processing Materials: 3feet Symons Cone Crusher is suitable for crushing metal and non-metal mines, cement plants, construction, sand metallurgy and other industries, non-ferrous metal ore, granite, limestone, quartzite, sandstone, cobblestone, bluestone, etc. Applied Filed: 3feet Symons cone crusher is widely used in metallurgy, construction, hydropower, transportation, chemical industry, building materials industry.
Advantages of 3feet Symons Cone Crusher
1. The 3feet Symons cone crusher is designed with a safety device, which greatly reduces the downtime.
2. The special crushing chamber of 3feet Symons cone crusher and its matching speed can significantly improve the fine material ratio and cube content of the final product, which greatly reduces the needle-like material and have better grain shape.
3. The "passing iron" system of 3feet Symons cone crusher has good stability and convenient cavity cleaning.
Maintenance of 3feet Symons Cone Crusher
1.Regularly check the fixing bolts of 3feet Symons cone crusher for fixing the dust seal slip ring.
2.Ensure the 3feet Symons cone crusher in operation with a full load, otherwise, the product grain will be too coarse.
3.Change the lubricating oil of 3feet Symons cone crusherfrequently, otherwise, it will accelerate the wear of gear, bowl-shaped bush and shaft sleeve.
4.The fixing condition of the slip ring of 3feet Symons cone crushershould be checked frequently to prevent the slip ring of the dust seal box from falling off and causing a lot of dust.
Technical parameters
Model NO. | Cavity Type | Max. Feeding size (mm) | Output size (mm) | Capacity (t/h) | Motor Power (kw) | Weight (t) |
PSGB0607 | Standard fine | 60 | 6-30 | 16-50 | 22 | 4.5 |
PSGB0609 | Standard medium | 80 | 10-38 | 18-65 | 22 | 4.5 |
PSGB0611 | Standard coarse | 90 | 13-38 | 22-70 | 22 | 4.5 |
PSGD0603 | Short head fine | 35 | 3-13 | 9-35 | 22 | 4.5 |
PSGD0605 | Short head coarse | 50 | 5-16 | 22-70 | 22 | 4.5 |
PSGB0910 | Standard fine | 85 | 9-22 | 45-91 | 75 | 9.98 |
PSGB0917 | Standard coarse | 150 | 13-38 | 59-163 | 75 | 9.98 |
PSGB0918 | Standard extra coarse | 150 | 25-38 | 118-163 | 75 | 9.98 |
PSGD0914 | Short head fine | 35 | 3-13 | 27-90 | 75 | 10.53 |
PSGD0906 | Short head medium | 65 | 3-16 | 27-100 | 75 | 10.53 |
PSGD0907 | Short head coarse | 85 | 6-19 | 59-129 | 75 | 10.53 |
PSGB1313 | Standard fine | 115 | 13-31 | 109-181 | 160 | 22.46 |
PSGB1321 | Standard medium | 178 | 16-38 | 132-253 | 160 | 22.46 |
