Applied Field: Jaw crusher plant can be widely applied in various industries such as mining, metallurgy, construction, roads, railways, water conservation and chemical industry.Jaw crusher plant can process granite, marble, basalt, limestone, quartz, gravel, iron ore, copper ore, etc.
The performance advantages of jaw crusherplant
1.The cavity of jaw crusher plant is deep and without a dead zone, which improves the feeding and processing capacity.
2.The crushing ratio of stone jaw crusher plant is high and the finished granularity is even.
3.The adjustment deviceof jaw crusher plant feeding mouthhas a wide range, which is so reliable and convenient that increases the flexibility of the jaw crusher plant.
4.The lubrication system of jaw crusher plant is safe, which makes the change of the parts is convenient and the maintenance work is low.
5.Jaw crusher plants adopt sliding bearings with high transmission efficiency and convenient maintenance.
Maintenance of Jaw Crusher Plant
1.The stone jaw crusher can not be fed until it is in normal operation.
2.The material to becrushedshould be evenly added into the crushing cavity to avoid side feeding and sudden changes in load or increase of unilateral.
3.Under normal working conditions, the bearing temperature rise should not exceed 35°C, and the high temperature should not exceed 70°C.
Technical Parameters
Model | Max. feeding size (mm) | Discharge size (mm) | Capacity (t/h) | Motor power (kw) | Weight (t) | Diemension (mm) |
PE150*250 | 125 | 10-40 | 1-3 | 5.5 | 0.7 | 1000*870*990 |
PE250*400 | 210 | 20-60 | 5-20 | 15 | 2.8 | 1300*1090*1270 |
PE400*600 | 340 | 40-100 | 16-60 | 30 | 7 | 1730*1730*1630 |
PE400*900 | 340 | 40-100 | 40-110 | 55 | 7.5 | 1905*2030*1658 |
PE500*750 | 425 | 50-100 | 40-110 | 55 | 12 | 1980*2080*1870 |
PE600*900 | 500 | 65-160 | 50-180 | 75 | 17 | 2190*2206*2300 |
PE750*1060 | 630 | 80-140 | 110-320 | 90 | 31 | 2660*2430*2800 |
PE900*1200 | 750 | 95-165 | 220-450 | 160 | 52 | 3380*2870*3330 |
PE1000*1200 | 850 | 195-265 | 315-500 | 160 | 55 | 3480*2876*3330 |
PEX150*750 | 120 | 18-48 | 8-25 | 15 | 3.8 | 1200*1530*1060 |
PEX250*750 | 210 | 15-60 | 13-35 | 30 | 6.5 | 1380*1750*1540 |
PEX250*1000 | 210 | 15-60 | 16-52 | 37 | 7 | 1560*1950*1390 |
PEX250*1200 | 210 | 15-60 | 20-61 | 45 | 9.7 | 2140*2096*1500 |
