Symons Cone Crusher Manual Pdf mainly include the structure, model, accessories, price, working principle, maintenance etc of Symons cone crusher plant. According to the Symons cone crusher manual pdf,customers can operate and improve the working efficiency of the symons cone crusher equipment more scientifically and reasonably.
Features ofSymons Cone Crusher Manual Pdf
1. Makes Symons cone crusher achieve high degree of automation
Automatic Symons Cone Crusher adopts a set of external lubrication systems including oil pumps, oil tanks, and pipelines. When the oil flow rate is too slow or too high or the oil temperature is too high, the Symons cone crusher will automatically shut down.
2. Makes the maintenance of Symons cone crusher easier
All spare parts of the Symons cone crusher can be disassembled and maintained from the top or side of the crusher. The fixed cone and the movable cone are easy to disassemble, without disassembling the mainframe and fastening bolts, and it is more convenient to replace the liner.There are more introductions about these in our Symons cone crusher maintenance manual pdf.
3. Guides Symons cone crusher to use good lubrication conditions
Symons cone crusher lubrication system uses the unique thin oil lubrication system, which greatly improves the service life of the equipment. The high-performance non-contact labyrinth seal is wear-free and improves the reliability of dust and ash blocking, which fundamentally eliminates the common failures of the original oil-water mixing of the spring cone crusher.
As one of the China Symons cone crusher suppliers, Nile Machinery has different types ofSymons cone crushers for sale. If you want to get our Symons cone crusher manual pdf, Symons cone crusher parts list, Symons cone crusher instruction manual pdf, and latest price list about that, just feel free to inquiry online.
Technical data
Model NO. | Cavity Type | Max. Feeding size (mm) | Output size (mm) | Capacity (t/h) | Motor Power (kw) | Weight (t) |
PSGB0607 | Standard fine | 60 | 6-30 | 16-50 | 22 | 4.5 |
PSGB0609 | Standard medium | 80 | 10-38 | 18-65 | 22 | 4.5 |
PSGB0611 | Standard coarse | 90 | 13-38 | 22-70 | 22 | 4.5 |
PSGD0603 | Short head fine | 35 | 3-13 | 9-35 | 22 | 4.5 |
PSGD0605 | Short head coarse | 50 | 5-16 | 22-70 | 22 | 4.5 |
PSGB0910 | Standard fine | 85 | 9-22 | 45-91 | 75 | 9.98 |
PSGB0917 | Standard coarse | 150 | 13-38 | 59-163 | 75 | 9.98 |
PSGB0918 | Standard extra coarse | 150 | 25-38 | 118-163 | 75 | 9.98 |
PSGD0914 | Short head fine | 35 | 3-13 | 27-90 | 75 | 10.53 |
PSGD0906 | Short head medium | 65 | 3-16 | 27-100 | 75 | 10.53 |
PSGD0907 | Short head coarse | 85 | 6-19 | 59-129 | 75 | 10.53 |
PSGB1313 | Standard fine | 115 | 13-31 | 109-181 | 160 | 22.46 |
PSGB1321 | Standard medium | 178 | 16-38 | 132-253 | 160 | 22.46 |
