Processing Materials: Single cylinder hydraulic cone crusher is suitable for crushing various ores and rocks with hard and medium hardness, such as gravel, dolomite, bluestone, granite, basalt, iron ore, limestone, quartz, diabase, gold ore, copper ore. Applied Filed: Single cylinder hydraulic cone crusher is widely used in metallurgy, construction, hydropower, transportation, chemical industry, building materials industry.
Product Description
The Nile single cylinder hydrauliccone crusher feeding size is 210-460mm, the output size is around 16-50mm,capacity is around 120-1200t/h.Single cylinder hydraulic cone crusher realizes multiple functions such as discharge port adjustment, cavity cleaning, iron passing, and overload protection by moving the cone up and down with using a single hydraulic cylinder. It's also equipped with an electronic intelligent discharge port control system to achieve production process control and operation optimization.
Advantages of single cylinder hydrauliccone crusher
1. Low production and operation cost
2. The various cavities for medium and fine crushing can be achieved by changing the fixed cone.
3. Advanced hydraulic technology realizes overload protection and hydraulic adjustment of the discharge port, which simplifies the structure and reduces the weight of the single cylinder hydrauliccone crusher.
Model | Max feed size | Output adjusting range | Power | Capacity | Weight |
HD300 | 210 | 16-44 | 250 | 120-260 | 16 |
HD400 | 350 | 30-50 | 315 | 200-340 | 20 |
HD500 | 400 | 40-60 | 400 | 400-600 | 33 |
