Applied Fields: Portable ball mill is widely used in silicate products, new building materials, cement, refractories, chemical fertilizer, ferrous and non-ferrous metal beneficiation, glass ceramics, etc., for dry or wet grinding of various ores and other grindable materials.
Technical Parameters
Model | Ball loading (t) | Feed size(мм) | Size | Performance engine power (kw) | Weight |
Ф900×1800 | 1.4 | ≤20 | 0.075-0.89 | 18.5 | 3.6 |
Ф900×2100 | 1.7 | ≤15 | 0.075-0.83 | 15 | 3.9 |
Ф900×3000 | 2.7 | ≤20 | 0.075-0.89 | 22 | 4.5 |
Ф1200×2400 | 3.5 | ≤25 | 0.075-0.6 | 30 | 11.5 |
Ф1200×2800 | 6.8 | ≤25 | 0.075-0.6 | 37 | 13 |
Ф1200×4500 | 5.5 | ≤25 | 0.074-0.4 | 55 | 13.8 |
Ф1500×3000 | 6.8 | ≤25 | 0.074-0.4 | 75 | 17 |
Ф1500×4500 | 10.5 | ≤25 | 0.074-0.4 | 110 | 21 |
Ф1500×5700 | 15 | ≤25 | 0.074-0.4 | 130 | 24.7 |
Ф1830×3000 | 13 | ≤25 | 0.074-0.4 | 160 | 28 |
Ф1830×3600 | 15 | ≤25 | 0.075-0.4 | 160 | 33.5 |
Ф1830×4500 | 17 | ≤25 | 0.075-0.6 | 185 | 35 |
Ф1830×7000 | 25 | ≤25 | 0.074-0.4 | 210 | 36 |
Ф2100×3600 | 21 | ≤25 | 0.074-0.4 | 185 | 46.8 |
Ф2200×5500 | 30 | ≤25 | 0.074-0.4 | 245 | 48.5 |
Ф2200×6500 | 35 | ≤25 | 0.074-0.4 | 380 | 52.8 |
Ф2200×7500 | 33 | ≤25 | 0.074-0.4 | 380 | 56 |
Ф2400×3000 | 30 | ≤25 | 0.075-0.4 | 245 | 59 |
Ф2400×4500 | 33 | ≤25 | 0.074-0.4 | 380 | 65 |
Ф2700×3600 | 39 | ≤25 | 0.074-0.4 | 400 | 91.3 |
Ф2700×4000 | 40 | ≤25 | 0.074-0.4 | 400 | 94 |
Ф2700×4500 | 48 | ≤25 | 0.074-0.4 | 430 | 102 |
Ф3200×4500 | 65 | ≤25 | 0.075-0.4 | 800 | 137 |
Ф3600×4500 | 90 | ≤25 | 0.074-0.4 | 850 | 158 |
Ф3600×6000 | 110 | ≤25 | 0.074-0.4 | 1250 | 175 |
Ф3600×8500 | 131 | ≤25 | 0.074-0.4 | 1800 | 252 |
Ф4000×5000 | 121 | ≤25 | 0.074-0.4 | 1500 | 203 |
Ф4000×6000 | 146 | ≤25 | 0.074-0.4 | 1600 | 218 |
Structure Characteristics of Portable Ball Mill
The design for portable ball mill is more scientific and reasonable. The main shaft adopts large diameter double row self-aligning roller bearing, which is light and fast in operation and can reduce the power consumption. At the same time, it greatly simplifies the transmission device, makes the reducer and gear work more smoothly, and the inspection and maintenance are more convenient and faster.
Product Advantages of Portable Ball Mill
1.The large size ball mill is equipped with jacking device, which is convenient for maintenance.
2.The large-scale ball mill has a slow transmission, which is easy to repair and start.
3.The large and small gears of the large ball mill adopt oil mist lubrication to ensure reliable lubrication of the large and small gears, prolong the service life, and save lubricating oil.
4. The large-scale ball mill is equipped with an air clutch, which adopts flexible starting to reduce the impact on the power grid of the beneficiation plant when the ball mill starts.
Technical Parameters of Portable Ball Mill
Model | Ball loading (t) | Feed size(мм) | Size | Performance engine power (kw) | Weight |
Ф900×1800 | 1.4 | ≤20 | 0.075-0.89 | 18.5 | 3.6 |
Ф900×2100 | 1.7 | ≤15 | 0.075-0.83 | 15 | 3.9 |
Ф900×3000 | 2.7 | ≤20 | 0.075-0.89 | 22 | 4.5 |
Ф1200×2400 | 3.5 | ≤25 | 0.075-0.6 | 30 | 11.5 |
Ф1200×2800 | 6.8 | ≤25 | 0.075-0.6 | 37 | 13 |
Ф1200×4500 | 5.5 | ≤25 | 0.074-0.4 | 55 | 13.8 |
Ф1500×3000 | 6.8 | ≤25 | 0.074-0.4 | 75 | 17 |
Ф1500×4500 | 10.5 | ≤25 | 0.074-0.4 | 110 | 21 |
Ф1500×5700 | 15 | ≤25 | 0.074-0.4 | 130 | 24.7 |
Ф1830×3000 | 13 | ≤25 | 0.074-0.4 | 160 | 28 |
Ф1830×3600 | 15 | ≤25 | 0.075-0.4 | 160 | 33.5 |
Ф1830×4500 | 17 | ≤25 | 0.075-0.6 | 185 | 35 |
Ф1830×7000 | 25 | ≤25 | 0.074-0.4 | 210 | 36 |
Ф2100×3600 | 21 | ≤25 | 0.074-0.4 | 185 | 46.8 |
Ф2200×5500 | 30 | ≤25 | 0.074-0.4 | 245 | 48.5 |
Ф2200×6500 | 35 | ≤25 | 0.074-0.4 | 380 | 52.8 |
Ф2200×7500 | 33 | ≤25 | 0.074-0.4 | 380 | 56 |
Ф2400×3000 | 30 | ≤25 | 0.075-0.4 | 245 | 59 |
Ф2400×4500 | 33 | ≤25 | 0.074-0.4 | 380 | 65 |
Ф2700×3600 | 39 | ≤25 | 0.074-0.4 | 400 | 91.3 |
Ф2700×4000 | 40 | ≤25 | 0.074-0.4 | 400 | 94 |
Ф2700×4500 | 48 | ≤25 | 0.074-0.4 | 430 | 102 |
Ф3200×4500 | 65 | ≤25 | 0.075-0.4 | 800 | 137 |
Ф3600×4500 | 90 | ≤25 | 0.074-0.4 | 850 | 158 |
Ф3600×6000 | 110 | ≤25 | 0.074-0.4 | 1250 | 175 |
Ф3600×8500 | 131 | ≤25 | 0.074-0.4 | 1800 | 252 |
Ф4000×5000 | 121 | ≤25 | 0.074-0.4 | 1500 | 203 |
Ф4000×6000 | 146 | ≤25 | 0.074-0.4 | 1600 | 218 |
