Feed size: ≤100mm
Production capacity: 5-100t/h
Applicable materials: pebbles, construction waste, river pebbles, quartz sand, granite, basalt, iron ore, limestone, etc.
| Model | PFL-800 | PFL-1000 | PFL-1250 | PFL-1500 | PFL-1750 |
| Motor diameter(mm) | 650 | 800 | 1000 | 1250 | 1560 |
| Barrel height(mm) | 800 | 850 | 850 | 1000 | 1410 |
| Shaft speed(r/min) | 1350 | 970 | 740 | 650 | 600 |
| Input size(mm) | 50 | 70 | 100 | 100 | 100 |
| Output size(mm) | 0-5 | 0-5 | 0-5 | 0-5 | 0-5 |
| Capacity(t/h) | 5-15 | 10-30 | 20-60 | 30-80 | 40-100 |
| Motor Power | 30 | 55 | 75 | 110 | 132 |
| Rotor speed(r/min) | 1440 | 1440 | 750 | 750 | 750 |
| Weight | 2.3 | 4.5 | 9.73 | 18.1 | 26.61 |
| Diemension(m) | 2.2*0.86*1.98 | 2.7*1.16*2 | 2.8*1.4*2.73 | 3.1*1.9*2.3 | 3.35*2.1*2.8 |
