Screw Sand Washer Machine For Sale

Product description:

Screw sand washing machine is a kind of sand washing machine, which is mainly used to stir the sand and gravel materials through the spiral device in the equipment, so that the soil and water in the sand and gravel materials are mixed and discharged from the orifice on the equipment, and the sand and gravel materials are Under the action of the screw device, it is gradually screened and discharged from the top discharge port, thereby achieving the cleaning and screening effect of sand and gravel.

Features:

1. Spiral sand washer machine adopts advanced technology, high washing degree, and simple structure.

2. A variety of functions, large processing capacity, the spiral sand washing machine has three functions of cleaning, dewatering, and grading.

3. High production efficiency and low maintenance cost

4. Long service life, low pollution, and low power consumption.

The use of screw sand washer machine for sale:

Spiral sand washing equipment is widely used for desliming and screening operations of large amounts of sand and gravel used in construction sites, sand and gravel plants, prefabrication plants, and hydropower sites, and can also be used for ore sorting operations.

Working principle:

The screw sand washer machine is generally inclined when installed. When it is working, the spiral starts to rotate under the action of the motor, and the sand enters the cleaning tank from the feeding trough, flips and collides with each other under the drive of the spiral, and then cleans. Impurities on the surface of the sand and gravel break the water vapor layer covering the sand at the same time to facilitate dehydration. The sand and gravel move from high to low under the action of the spiral and its own gravity, and the clean gravel enters the discharge chute from the rotation. , Complete the cleaning effect of sand and gravel.

Installation and debugging of spiral sand washing machine:

1. For the spiral sand washing machine, the user should immediately check whether all parts are complete and whether they are damaged. After confirming that the machine is intact, the installation can be carried out.

2. The user should design the foundation construction drawing of the spiral sand washing machine according to the specific situation of the site, and install the stone washing machine firmly on the solid concrete foundation.

3. During installation, the stone washing machine must be installed at an inclination angle according to the requirements of the installation drawing.

4. The motor of the spiral sand washer is installed on the guide rail to adjust the tightness of the belt. The pulley and the motor pulley should be parallel when installed.

5. After adjusting according to the above requirements, rotate the rotor disc a few times to check whether there is jamming or collision.
