Application Field：cone crusher machine is widely used in metallurgy, mining, building materials, and other industries that can break all kinds of hard stone and rock, such as river pebble, granite, marble, limestone, fluorite ore, gold ore, barite, etc.
Advantages:
1.After completing the adjustment of the discharge port, the locking of the adjusting sleeve is completed by the hydraulic locking cylinder. You only need to press a button to complete the work of locking the adjustment sleeve, which greatly reduces labor intensity and downtimeof the cone crusher machine, and ensures the reliability of the locking.
2.The adjustment of the discharge opening is realized by the adjustment sleeve driven by the hydraulic motor, and the adjustment sleeve is locked by the hydraulic locking cylinder so that you can complete the adjustment of the discharge port without arriving at the site.
3.The newly designed integrated base contains the main equipment, motor, belt guard, and other installation modules, which simplifies the installation steps of the cone crusher machineand brings great convenience to users.
NileMachinery is a large-scale mining machine manufacturer integrating scientific research, production, and sales with more than 30 years of history.You can inquiry online about our cone crusher machine at any time, and the technical manager will provide you with various services such as installation, debugging, commissioning and maintenance, etc.
Technical Parameters
Model | Type of cavity | Min output | Feed opening size | Capacity | Motor power | Moving cone diameter |
(mm) | (mm) | (t/h) | (kw) | (mm) | ||
HPY200 | C | 13 | 150 | 120-240 | 160 | 950 |
F | 6 | 76 | 55-180 | |||
HPY300 | C | 13 | 225 | 150-430 | 220 | 1160 |
F | 6 | 86 | 90-260 | |||
HPY400 | C | 13 | 290 | 190-610 | 315 | 1400 |
F | 6 | 100 | 108-320 | |||
HPY500 | C | 13 | 320 | 230-700 | 400 | 1500 |
F | 6 | 110 | 145-430 | |||
HPY800 | C | 13 | 350 | 325-1150 | 630 | 1800 |
F | 8 | 120 | 245-730 |
