Porcessing Materials: Stone cone crusher can process raw materials with hard strength and the above strength, such as the iron ore, limestone, granite, basalt, quartz etc. Applied Field: Stone cone crusher is widely used in building materials, mining, chemical industries, smelting, highways, water conservancy and railways etc.
Advantages of Stone Cone Crusher
1. The moving cone is under good stress conditions, and the spare parts (bearing copper parts) have a long service life.
2. The effect of medium crushing is good, the ability to passis high.
3. Fully realize intelligent control, realize the dynamic adjustment of load with discharge port, motor power, and crusher pressure, and display various operating parameters in real-time. When the unmanned operation is reached, the discharge port is automatically detected and adjusted.
4. Supported at both ends of the spindle, with large carrying capacity and compact structure.
As the leading mining crusher manufacturer with more than 30years of history in China, Nile Machinerywill provide a professional stone cone crusherfor you. Welcome to contact us to know the maximum discount.
Technical Parameter
Model NO. | Type of Cavity | Output Size (mm) | Max. Feeding Size (mm) | Capacity (t/h) | Motor Power (kw) | Moving cone Diemeter (mm) |
HPY200 | C | 13 | 150 | 120-240 | 160 | 950 |
F | 6 | 76 | 55-180 | 160 | 950 | |
HPY300 | C | 13 | 225 | 150-430 | 220 | 1160 |
F | 6 | 86 | 90-260 | 220 | 1160 | |
HPY400 | C | 13 | 290 | 190-610 | 315 | 1400 |
F | 6 | 100 | 108-320 | 315 | 1400 | |
HPY500 | C | 13 | 320 | 230-700 | 400 | 1500 |
F | 6 | 110 | 145-430 | 400 | 1500 | |
HPY600 | C | 13 | 350 | 325-1150 | 630 | 1800 |
F | 8 | 120 | 245-730 | 630 | 1800 |
