Processing Materials: VSI sand making machinery is one of the commonly used production lines in sand making production line. VSI sand making machinery has a high degree of automation and high crushing rate, which can more than 200 kinds of materials, such as pebbles, granite, bluestone, iron ore, limestone, quartz, etc.
Configuration of VSI Sand Making Machinery
VSI sand making machinery is mainly composed of vibrating feeder, jaw crusher, impact crusher, sand making machine, vibrating screen, belt conveyor, centralized electric control, and other equipment. The design output of VSI sand making machinery is generally 50-800t / h. In order to meet the different processing needs of customers, the VSI sand making machine can be equipped with a cone crusher, sand making machine, dust removal equipment, etc.
Performance Advantages of VSI Sand Making Machinery
1.VSI sand making machinery has more convenient maintenance and operation mode. Compared with other production line equipment, it is easy to maintain. The vulnerable parts of VSI sand making machines are made of new domestic high-strength wear-resistant materials with low loss and long service life, which can bring considerable economic benefits to customers.
2.VSI sand making machine adopts fully automated operation process, which has higher production efficiency, more optimized work efficiency, large crushing ratio, and processing capacity. After crushing, the finished products are cube-shaped with low content of needle and flake, no internal cracks, and high compressive strength.
Technical Parameters of VSI Sand Making Machinery
Model No. | VSI7611 | VSI8518 | VSI9526 | VSI1140 | VSI1145 | |
Capacity | Cascade Feeding | 120-180 | 200-260 | 300-380 | 450-520 | 500-640 |
Full Central Feeding | 60-90 | 100-130 | 150-190 | 225-260 | 250-360 | |
Max. Feeding size(mm) | Soft Material | 35 | 40 | 45 | 50 | 50 |
Hard Material | 30 | 35 | 40 | 45 | 45 | |
Rotation Speed (r/min) | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | 1100-1310 | |
Model of Motor | Y250M-4 | Y280M-4 | Y315M-4 | Y315L2-4 | Y315L2-4 | |
Double Motor Power | 55*2 | 90*2 | 132*2 | 200*2 | 220*2 | |
Weight (t) | 10 | 12 | 16 | 25.6 | 27.5 |
