Processing Materials: The VSI stone crusher can be widely used in crushing and shaping of metal and nonmetal ores, building materials, artificial sand making and various metallurgical slag. VSIstone crusher machine is suitable for brittle materials with Mohs hardness less than 9 grades, not suitable for viscous materials and stone materials with a lot of soil.
Working Principle of Vsi Stone Crusher
VSI stone crusher is to use the friction of high-speed moving materials to crush each other between materials. VSI stone crusher not only can crush stone materials but also can reshape stone.
Performance Characteristics of VSI Stone Crusher
1.VSI stone crusher adopts a variety of crushing methods, which can meet the crushing needs of different materials.
2.Imported bearings are used for vsi stone crusher machine to ensure the stable operation of the machine.
3.Double oil pump design: only one oil pump works during normal use of vsi stone crusher. The second oil pump works only when the pressure and flow can not reach the set value, or when the first oil pump fails, the second oil pump starts automatically to ensure the normal operation of the main engine.
4.The new impeller design of vsi stone crusher optimizes the material flow direction, and improve the output 30% higher than the old vsi stone crusher under the same power.
Technical Parameters of VSI Stone Crusher
Model No. | VSI7611 | VSI8518 | VSI9526 | VSI1140 | VSI1145 | |
Capacity | Cascade Feeding | 120-180 | 200-260 | 300-380 | 450-520 | 500-640 |
Full Central Feeding | 60-90 | 100-130 | 150-190 | 225-260 | 250-360 | |
Max. Feeding size(mm) | Soft Material | 35 | 40 | 45 | 50 | 50 |
Hard Material | 30 | 35 | 40 | 45 | 45 | |
Rotation Speed (r/min) | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | 1100-1310 | |
Model of Motor | Y250M-4 | Y280M-4 | Y315M-4 | Y315L2-4 | Y315L2-4 | |
Double Motor Power | 55*2 | 90*2 | 132*2 | 200*2 | 220*2 | |
Weight (t) | 10 | 12 | 16 | 25.6 | 27.5 | |
